Function |
Description |
|
LCD Size |
4:3 12.1” |
|
Max. Resolution |
XGA 1024x768 |
|
Luminance (cd/m2) |
350 |
|
Contrast Ratio |
800 |
|
Viewing Angle |
85(U), 85(D), 85(L), 85(R) |
|
Backlight |
LED |
|
LCD Color |
16.7M |
|
Touch Screen |
12.1” Resistive Single Touch Panel (1 point) |
|
Touch Light Transmission |
79% |
|
CPU |
Intel® Celeron® Processor J1900 2.42GHz |
|
Memory |
2 x DDR3L SO-DIMM, up to 8GB, default 2GB |
|
Storage |
1x 2.5” SATA HDD, default 2.5” 64G MLC SSD |
|
Additional Display Port |
VGA/DVI-D |
|
Ethernet (10/100/1000) |
2 |
|
USB2.0/USB3.0 |
2/1 |
|
COM Port |
2 |
|
Audio |
MIC in/ Line in/Line out phone jack |
|
Power Jack |
3-pin Terminal block |
|
Power Button |
Rock switch |
|
Expansion |
2x Mini PCIe/1x PCIe/1x PCI |
|
Mounting |
Panel/VESA 75 x 75mm, 100 x 100mm |
|
Power Input |
12 ~ 24VDC |
|
Operating Temp. |
0°C to 50°C (with SSD) |
|
Storage Temp. |
-20°C to 60°C |
|
IP Level |
IP65 Front bezel/IP30 Back system |
|
Certification |
CE/FCC, LVD, CB, CCC |
|
OS Support |
Windows 7 Professional/WES 7, WES 8/Windows 8.1/Windows 10/Linux Kernel 3.X |
|
Dimension (WxHxD)(mm) |
320 x 270 x 101 mm |
|
Weight(kg) |
7.5 Kg |
-
